A totally different glider with its concept based on Bagheera and
Tigra. Allegra boasts exceptional performance and exciting handling but
retains its easy character with the forgiveness of a biginner glider on
the ground and in the air. No parallel wing exists today, which
delivers such incredible performance combined with Standard Class
safety.Relax, enjoy and surrender to the rhythm of the flight - the rhythm of Allegra.
|
 |
|
Allegra is a performance glider that carries on the success that the
Futura achieved. The Allegra has a modern concept and design. It is
based on a new Hi-Tech profile found on the Tigra and Bagheera. The
Allegra is a remarkable improvement on the Futura in all aspects: it
has sporty, quick and immediate handling, superior performance (over
the Futura) and has easy, friendly behavior. The 4 sizes of the glider
are fully certified in Standard class by ACPUL/AFNOR/CEN and DHV Class
1-2 Trim and Accelarated in Small Medium and Large. It is a major achievement for us to launch a glider that exceeds the Futura in performance and handling and in addition is certified in Standard class. This proves and reconfirms the safety of this new glider. It was also our prime goal to launch a glider for the "Recreational" pilot that could deliver Top-class performance combined with Standard class Safety. We are finally there and believe that there is no parallel product that exists on the market today. The glider is also cut in a new color design, to make it look both, contemporary and fresh. The glider is in full production and orders are welcome. |
| Allegra Technical Data | ||||
| Size | X-Small | Small | Medium | Large |
| Cells | (32x3)+4 | (33x3)+4 | (35x3)+4 | (37x3)+4 |
| Area m2 | 26.20 | 27.20 | 29.10 | 31.00 |
| Area (projected) m2 | 23.30 | 24.50 | 25.80 | 27.50 |
| Span (incl. Stabiliser) m | 11.65 | 11.98 | 12.65 | 13.32 |
| Span (projected) m | 9.50 | 10.20 | 10.50 | 11.00 |
| Aspect Ratio | 5.20 | 5.30 | 5.50 | 5.70 |
| Aspect Ratio (projected) | 3.90 | 4.20 | 4.30 | 4.40 |
| Pilot Weight, Kg (all up) | 60 - 75 | 73 - 90 | 85 - 105 | 100 - 120 |
| Weight of Canopy Kg | 6.7 | 7.0 | 7.4 | 7.6 |
| Root Cord m | 2.9 | 2.9 | 2.9 | 2.9 |
| Tip Cord m | 0.59 | 0.59 | 0.59 | 0.59 |
| Length of Lines on B m | 7.19 | 7.19 | 7.59 | 7.96 |
| Total length of line used m | 370 | 370 | 384 | 402 |
| Allegra Performance Data | |
| V-min. | 21 km/h |
| V-trim | 35 km/h |
| V-max. | 46 km/h |
| Min Sink ( at optimum wing loading) | 1.0m/s |
| Allegra Colour Options | ||
| Colour | Bottom Surface | Top Surface |
| Yellow |  |
 |
| Red |  |
 |
| Turquoise |  |
 |
| Violet |  |
 |
| Allegra Certification | ||
| Size/Type | AFNOR / CEN | DHV |
| XS | Standard | No |
| S | Standard | Class 1-2 (Trim & Accelerated) |
| M | Standard | Class 1-2 (Trim & Accelerated) |
| L | Standard | Class 1-2 (Trim & Accelerated) |
| Allegra Construction/Materials | |||
| Lines | Material | Diameter | Strength |
| Top | Dyneema | 0.8mm | 90kg |
| Mid | Super Aramid | 1.1mm | 80kg |
| Lower | Super Aramid | 1.7mm | 150kg |
| Central Lower | Super Aramid | 2.2mm | 220kg |
| Brake Cascades | Dyneema | 1.1mm | 90kg |
| Steering Line | Polyester | 2.2mm | 90kg |
| Fabric | |||
| Sail Cloth | 46gr/m2 "Zero Porosity" Ripstop Nylon | ||
| Rib Reinforcement | 180gr/m2 Mylar (Trilam) | ||
| Warranty | 3 Years / 250 hours | ||
